Gateway API v1.3 [2026] Multi-Cluster Traffic Cheat Sheet

The important facts for Gateway API v1.3 are concrete: v1.3.0 was released on April 24, 2025, it runs on Kubernetes 1.26+, and it adds percentage-based request mirroring to the Standard channel. For multi-cluster traffic, the practical pattern is to keep routing logic in Gateway and HTTPRoute, then choose whether backends stay cluster-local with Service or expand cluster-wide with ServiceImport.

• v1.3.0 shipped on April 24, 2025.
• Kubernetes 1.26+ is enough to run the API bundle.
• RequestMirror can mirror by percent or fraction.
• ServiceImport means ClusterSet-wide endpoints; Service means local endpoints.
• Experimental kinds introduced in v1.3 moved under gateway.networking.x-k8s.io.

What v1.3 Shipped

Confirmed facts from the official release

• v1.3.0 became generally available on April 24, 2025.
• The main new Standard-channel feature is percentage-based request mirroring.
• The new experimental features called out in the official announcement were CORS filters, XListenerSet, and retry budgets via XBackendTrafficPolicy.
• As of the official announcement, 4 implementations were already conformant for v1.3 experimental-channel features.

Resource and channel map

Searchable Command Reference

kubectl apply --server-side -f https://github.com/kubernetes-sigs/gateway-api/releases/download/v1.3.0/standard-install.yaml

kubectl apply --server-side -f https://github.com/kubernetes-sigs/gateway-api/releases/download/v1.3.0/experimental-install.yaml

kubectl get crd | grep gateway.networking
kubectl api-resources --api-group=gateway.networking.k8s.io
kubectl api-resources | grep multicluster

kubectl get gatewayclass,gateway,httproute,grpcroute,referencegrant -A

kubectl get gateway edge -n infra -o yaml
kubectl describe httproute web -n app
kubectl wait --for=condition=Programmed gateways.gateway.networking.k8s.io/edge -n infra --timeout=120s

kubectl get gateway edge -n infra \
  -o jsonpath='{range .status.listeners[*]}{.name}{"\t"}{.attachedRoutes}{"\n"}{end}'

kubectl get serviceexport,serviceimport -A
kubectl get endpointslice -A | grep clusterset

kubectl get httproute web -n app \
  -o jsonpath='{range .status.parents[*]}{.parentRef.name}{"\t"}{range .conditions[*]}{.type}{"="}{.status}{" "}{end}{"\n"}{end}'

Core Config Patterns

1. Smallest useful Gateway plus HTTPRoute

apiVersion: gateway.networking.k8s.io/v1
kind: Gateway
metadata:
  name: edge
  namespace: infra
spec:
  gatewayClassName: example
  listeners:
  - name: http
    protocol: HTTP
    port: 80
    allowedRoutes:
      namespaces:
        from: Same
---
apiVersion: gateway.networking.k8s.io/v1
kind: HTTPRoute
metadata:
  name: web
  namespace: infra
spec:
  parentRefs:
  - name: edge
    sectionName: http
  hostnames:
  - app.example.com
  rules:
  - backendRefs:
    - name: web
      port: 8080

2. Cross-namespace backend access with ReferenceGrant

If application teams own routes and platform teams own backends in another namespace, you need ReferenceGrant. Without it, attachment may look valid at a glance but fail in status.

apiVersion: gateway.networking.k8s.io/v1
kind: HTTPRoute
metadata:
  name: store
  namespace: app
spec:
  parentRefs:
  - name: edge
    namespace: infra
  rules:
  - matches:
    - path:
        type: PathPrefix
        value: /store
    backendRefs:
    - name: store
      namespace: backend
      port: 8080
---
apiVersion: gateway.networking.k8s.io/v1
kind: ReferenceGrant
metadata:
  name: allow-store
  namespace: backend
spec:
  from:
  - group: gateway.networking.k8s.io
    kind: HTTPRoute
    namespace: app
  to:
  - group: core
    kind: Service

3. Keep manifests readable

• Prefer one listener per intent: public HTTP, public HTTPS, internal gRPC, and mesh-adjacent routes should not be mixed casually.
• Use explicit sectionName in parentRefs so route attachment stays readable after listener growth.
• Normalize YAML before reviews; a quick pass through the Code Formatter keeps policy and route diffs tighter.

Multi-Cluster Traffic Patterns

The mental model

• Service means endpoints from the local cluster only.
• ServiceImport means endpoints from across the ClusterSet.
• ServiceExport is how a cluster contributes a local service into the ClusterSet-wide view.
• DNS expectations also change: local services resolve under cluster.local, while multi-cluster services resolve under clusterset.local.

Export a service into the ClusterSet

apiVersion: multicluster.x-k8s.io/v1alpha1
kind: ServiceExport
metadata:
  name: store
  namespace: app

Route to a ClusterSet-wide backend with ServiceImport

apiVersion: gateway.networking.k8s.io/v1
kind: HTTPRoute
metadata:
  name: store-global
  namespace: app
spec:
  parentRefs:
  - name: edge
    namespace: infra
  rules:
  - matches:
    - path:
        type: PathPrefix
        value: /store
    backendRefs:
    - group: multicluster.x-k8s.io
      kind: ServiceImport
      name: store
      port: 8080

Blend local and global traffic during rollout

This pattern is one of the most useful operational tricks in the official GEP-1748 model: keep most traffic local while bleeding a small slice to a ClusterSet-wide backend.

apiVersion: gateway.networking.k8s.io/v1
kind: HTTPRoute
metadata:
  name: store-hybrid
  namespace: app
spec:
  parentRefs:
  - name: edge
    namespace: infra
  rules:
  - backendRefs:
    - kind: Service
      name: store
      port: 8080
      weight: 90
    - group: multicluster.x-k8s.io
      kind: ServiceImport
      name: store-global
      port: 8080
      weight: 10

Route by region or cluster slice

• Create separate ServiceImport objects such as store-west and store-east when geography matters.
• Use path or hostname matching in HTTPRoute to steer traffic to those imported services.
• Keep the fallback rule pointed at the broad store import so unmatched requests still land somewhere predictable.

Advanced Usage and Debugging

Use RequestMirror for low-risk cross-cluster validation

The official v1.3 release added partial mirroring to the Standard channel. That matters for multi-cluster work because you can validate a remote backend without sending live responses from it.

apiVersion: gateway.networking.k8s.io/v1
kind: HTTPRoute
metadata:
  name: store-mirror
  namespace: app
spec:
  parentRefs:
  - name: edge
    namespace: infra
  hostnames:
  - store.example.com
  rules:
  - backendRefs:
    - name: store
      port: 8080
    filters:
    - type: RequestMirror
      requestMirror:
        backendRef:
          group: multicluster.x-k8s.io
          kind: ServiceImport
          name: store-canary
          port: 8080
        percent: 10

What to check when traffic does not move

• Confirm the GatewayClass controller is actually installed and reconciles your chosen class name.
• Check Gateway and HTTPRoute status conditions for Accepted, Programmed, and ResolvedRefs.
• Verify the target ServiceImport exists in the same namespace the route expects.
• Make sure your controller supports the exact experimental interaction you are using; conformance on core routing is not the same as conformance on ServiceImport backends.
• Inspect EndpointSlice objects when traffic is black-holing; imported services still need healthy exported endpoints behind them.

Implementation-minded checklist

• Default to the Standard bundle unless you can name the experimental feature you need.
• Keep multi-cluster rollout logic in routes, not in duplicated listener sprawl.
• Prefer weighted migration over cutover when moving from local Service to ServiceImport.
• Document which namespaces may create routes, which may create grants, and which own gateways.
• Treat controller conformance tables as part of design input, not marketing material.
