Kubernetes Security: PSA and Network Policies [2026]

Securing a Kubernetes cluster is easier when you separate admission-time controls from runtime traffic controls. Pod Security Admission evaluates pod specs before they are stored, while NetworkPolicy restricts which pods can talk to each other after scheduling. This tutorial shows a practical rollout: apply Pod Security Admission labels to one namespace, then add a default-deny ingress policy with a single explicit allow path.

• Pod Security Admission is built in and stable from Kubernetes 1.25 onward.
• Namespace labels drive enforce, audit, and warn behavior.
• A default-deny ingress policy blocks lateral access until you open only what is needed.
• Your CNI plugin must implement NetworkPolicy or traffic will remain unrestricted.

Prerequisites

Implement Pod Security Admission

1. Label a namespace for a safe first rollout

The fastest mistake with Pod Security Admission is jumping straight to restricted enforcement on a busy namespace. A safer pattern is to enforce the baseline profile while using audit and warn for restricted. The latest label value is supported for version labels, so you do not have to hard-code a minor release number in this tutorial.

apiVersion: v1
kind: Namespace
metadata:
  name: secure-demo
  labels:
    pod-security.kubernetes.io/enforce: baseline
    pod-security.kubernetes.io/enforce-version: latest
    pod-security.kubernetes.io/audit: restricted
    pod-security.kubernetes.io/audit-version: latest
    pod-security.kubernetes.io/warn: restricted
    pod-security.kubernetes.io/warn-version: latest

kubectl apply -f namespace.yaml
kubectl get ns secure-demo --show-labels

That gives you an immediate control boundary for obviously unsafe pods while surfacing stricter restricted gaps in warnings and audit output.

2. Prove the admission check works

Now create a pod that should be rejected by the baseline policy because it requests a privileged container.

apiVersion: v1
kind: Pod
metadata:
  name: privileged-test
  namespace: secure-demo
spec:
  containers:
  - name: shell
    image: busybox:1.36
    command:
    - sh
    - -c
    - sleep 3600
    securityContext:
      privileged: true

kubectl apply -f privileged-test.yaml

You should see a forbidden response from the API server referencing a PodSecurity violation. That validates the admission control path before you touch production namespaces.

For real rollouts, dry-run first and review warnings. If you need to paste manifests or warning output into tickets, scrub cluster-specific names and addresses with TechBytes' Data Masking Tool.

Lock Down East-West Traffic

3. Deploy a tiny app and two client pods

Next, create one server pod behind a service, one allowed client, and one client that should be blocked. This keeps verification simple and makes the effect of the policy obvious.

apiVersion: apps/v1
kind: Deployment
metadata:
  name: api
  namespace: secure-demo
spec:
  replicas: 1
  selector:
    matchLabels:
      app: api
  template:
    metadata:
      labels:
        app: api
    spec:
      containers:
      - name: api
        image: registry.k8s.io/e2e-test-images/agnhost:2.53
        args:
        - netexec
        - --http-port=8080
        ports:
        - containerPort: 8080
---
apiVersion: v1
kind: Service
metadata:
  name: api
  namespace: secure-demo
spec:
  selector:
    app: api
  ports:
  - port: 8080
    targetPort: 8080
---
apiVersion: v1
kind: Pod
metadata:
  name: client-allowed
  namespace: secure-demo
  labels:
    access: granted
spec:
  containers:
  - name: client
    image: busybox:1.36
    command:
    - sh
    - -c
    - sleep 3600
---
apiVersion: v1
kind: Pod
metadata:
  name: client-blocked
  namespace: secure-demo
spec:
  containers:
  - name: client
    image: busybox:1.36
    command:
    - sh
    - -c
    - sleep 3600

kubectl apply -f app-and-clients.yaml
kubectl wait --for=condition=Available deployment/api -n secure-demo --timeout=90s
kubectl get pods -n secure-demo

4. Add default-deny ingress and one allow rule

A pod becomes isolated for ingress when at least one policy selects it. The cleanest pattern is a namespace-wide default deny, then a narrow allow policy for the application port and source selector you actually need.

apiVersion: networking.k8s.io/v1
kind: NetworkPolicy
metadata:
  name: default-deny-ingress
  namespace: secure-demo
spec:
  podSelector: {}
  policyTypes:
  - Ingress
---
apiVersion: networking.k8s.io/v1
kind: NetworkPolicy
metadata:
  name: allow-api-from-granted-clients
  namespace: secure-demo
spec:
  podSelector:
    matchLabels:
      app: api
  policyTypes:
  - Ingress
  ingress:
  - from:
    - podSelector:
        matchLabels:
          access: granted
    ports:
    - protocol: TCP
      port: 8080

kubectl apply -f network-policies.yaml
kubectl get networkpolicy -n secure-demo

This policy set does exactly two things:

• It isolates every pod in the namespace for ingress by default.
• It allows only pods labeled access: granted to reach pods labeled app: api on TCP 8080.

Verification and Expected Output

1. Confirm the namespace labels are present.

   kubectl get ns secure-demo --show-labels

   Expected result: the namespace shows the six pod-security.kubernetes.io/* labels you applied.

2. Confirm the privileged pod is rejected.

   kubectl apply -f privileged-test.yaml

   Expected result: the API server returns a forbidden error mentioning a PodSecurity violation.

3. Test the allowed path.

   kubectl exec -n secure-demo client-allowed -- nc -vz -w 3 api 8080

   Expected result: the TCP connection succeeds.

4. Test the blocked path.

   kubectl exec -n secure-demo client-blocked -- nc -vz -w 3 api 8080

   Expected result: the command times out or exits non-zero because the ingress policy blocks the connection.

Troubleshooting Top 3

1. Existing workloads throw warnings after labeling the namespace

This is normal when you add warn or audit labels. Treat the warnings as a migration queue:

• Review which controls fail most often, usually runAsNonRoot, seccompProfile, or privilege escalation settings.
• Apply labels first in a lower environment, then repeat in production.
• Move to stronger enforcement only after the namespace is clean under the stricter profile.

2. NetworkPolicy applied, but traffic still flows

This nearly always points to enforcement, not YAML syntax.

• Verify your CNI plugin supports NetworkPolicy.
• Check that the policy selects the right destination pods with podSelector.
• Check that the source pod labels actually match the from rule.

3. You later add default-deny egress and DNS breaks

That is expected unless you allow DNS explicitly.

• Add an egress rule for your cluster DNS pods or DNS service path.
• Re-test name resolution before concluding the app itself is broken.
• When sharing failing manifests or logs outside the team, sanitize them with the Data Masking Tool so internal hostnames and addresses do not leak.

What's Next

This tutorial establishes a strong baseline, but it should not be your stopping point. The next hardening pass is usually straightforward:

• Move high-confidence namespaces from baseline enforcement to restricted enforcement.
• Add default-deny egress with explicit allowances for DNS, telemetry, and required upstream services.
• Pair admission and network controls with RBAC, image signing or policy checks, and secret management.
• Automate validation in CI so unsafe manifests never reach the cluster API in the first place.

The important architectural point is simple: Pod Security Admission decides what may run, and NetworkPolicy decides who may talk. Roll out both controls namespace by namespace, verify behavior with small tests, and the cluster becomes materially harder to misuse or move through laterally.
