OpenTelemetry Security Observability Tutorial [2026]

Real-time security observability works best when detection data is emitted by the application, not reconstructed hours later from fragmented logs. In this walkthrough, you’ll build a small OpenTelemetry pipeline that captures failed login attempts as traces, logs, and metrics; redacts sensitive fields in the Collector; and turns those events into a counter you can alert on immediately. The stack here is current for May 06, 2026 and uses official OpenTelemetry Go and Collector components.

Prerequisites

Step 1: Start the Collector

The Collector is the control plane for this pattern. It receives OTLP data, masks risky attributes, routes high-value security logs into a dedicated pipeline, and emits a metric every time an auth failure appears. That metric becomes your alert primitive.

Create the Collector config

extensions:
  health_check: {}

receivers:
  otlp:
    protocols:
      http:

processors:
  batch: {}
  resource/security:
    attributes:
      - key: security.pipeline
        value: realtime
        action: upsert
  redaction/security:
    allow_all_keys: true
    blocked_key_patterns:
      - ".*header.*"
      - ".*token.*"
      - ".*password.*"
    summary: debug

connectors:
  routing/security:
    default_pipelines: [logs/default]
    table:
      - context: log
        condition: 'attributes["security.event"] == "auth.failure"'
        pipelines: [logs/security]
  count/security:
    logs:
      security_auth_failures_total:
        description: Count failed authentication log records.
        conditions:
          - 'attributes["security.event"] == "auth.failure"'

exporters:
  debug/default:
    verbosity: basic
  debug/security:
    verbosity: detailed

service:
  extensions: [health_check]
  pipelines:
    traces:
      receivers: [otlp]
      processors: [resource/security, batch]
      exporters: [debug/default]
    logs/in:
      receivers: [otlp]
      processors: [resource/security, redaction/security, batch]
      exporters: [routing/security, count/security]
    logs/default:
      receivers: [routing/security]
      exporters: [debug/default]
    logs/security:
      receivers: [routing/security]
      exporters: [debug/security]
    metrics/security:
      receivers: [count/security]
      exporters: [debug/default]

Run the Collector

docker run --rm \
  -p 4318:4318 \
  -p 13133:13133 \
  -v "$(pwd)/otelcol.yaml:/etc/otelcol-contrib/config.yaml" \
  otel/opentelemetry-collector-contrib:0.150.0

This uses the official Contrib image and the documented config path for Docker-based Collector runs. If you already have a central Collector, keep the same logical pipeline but move the exporters from debug to your real backend.

Step 2: Instrument the Go Service

Now wire a Go login service to emit traces, metrics, and logs over OTLP/HTTP. The official Go docs support this shape directly: traces via otlptracehttp, metrics via otlpmetrichttp, and logs via otlploghttp.

Install the dependencies

go get go.opentelemetry.io/contrib/bridges/otelslog \
  go.opentelemetry.io/contrib/instrumentation/net/http/otelhttp \
  go.opentelemetry.io/otel \
  go.opentelemetry.io/otel/exporters/otlp/otlpmetric/otlpmetrichttp \
  go.opentelemetry.io/otel/exporters/otlp/otlplog/otlploghttp \
  go.opentelemetry.io/otel/exporters/otlp/otlptrace/otlptracehttp \
  go.opentelemetry.io/otel/sdk/log \
  go.opentelemetry.io/otel/sdk/metric \
  go.opentelemetry.io/otel/sdk/resource \
  go.opentelemetry.io/otel/sdk/trace

Add OpenTelemetry setup and the login handler

package main

import (
  "context"
  "errors"
  "log/slog"
  "net/http"
  "time"

  "go.opentelemetry.io/contrib/bridges/otelslog"
  "go.opentelemetry.io/contrib/instrumentation/net/http/otelhttp"
  "go.opentelemetry.io/otel"
  "go.opentelemetry.io/otel/attribute"
  "go.opentelemetry.io/otel/codes"
  logglobal "go.opentelemetry.io/otel/log/global"
  "go.opentelemetry.io/otel/metric"
  "go.opentelemetry.io/otel/exporters/otlp/otlpmetric/otlpmetrichttp"
  "go.opentelemetry.io/otel/exporters/otlp/otlplog/otlploghttp"
  "go.opentelemetry.io/otel/exporters/otlp/otlptrace/otlptracehttp"
  sdklog "go.opentelemetry.io/otel/sdk/log"
  sdkmetric "go.opentelemetry.io/otel/sdk/metric"
  "go.opentelemetry.io/otel/sdk/resource"
  sdktrace "go.opentelemetry.io/otel/sdk/trace"
)

var (
  tracer = otel.Tracer("auth-api")
  meter  = otel.Meter("auth-api")
  logger *slog.Logger
  failedLogins metric.Int64Counter
)

func setupOTel(ctx context.Context) (func(context.Context) error, *sdklog.LoggerProvider, error) {
  res := resource.NewWithAttributes("",
    attribute.String("service.name", "auth-api"),
    attribute.String("deployment.environment.name", "prod"),
  )

  traceExp, err := otlptracehttp.New(ctx,
    otlptracehttp.WithEndpoint("localhost:4318"),
    otlptracehttp.WithInsecure(),
  )
  if err != nil { return nil, nil, err }

  metricExp, err := otlpmetrichttp.New(ctx,
    otlpmetrichttp.WithEndpoint("localhost:4318"),
    otlpmetrichttp.WithInsecure(),
  )
  if err != nil { return nil, nil, err }

  logExp, err := otlploghttp.New(ctx,
    otlploghttp.WithEndpoint("localhost:4318"),
    otlploghttp.WithInsecure(),
  )
  if err != nil { return nil, nil, err }

  tp := sdktrace.NewTracerProvider(
    sdktrace.WithBatcher(traceExp),
    sdktrace.WithResource(res),
  )

  mp := sdkmetric.NewMeterProvider(
    sdkmetric.WithResource(res),
    sdkmetric.WithReader(sdkmetric.NewPeriodicReader(metricExp, sdkmetric.WithInterval(5*time.Second))),
  )

  lp := sdklog.NewLoggerProvider(
    sdklog.WithResource(res),
    sdklog.WithProcessor(sdklog.NewBatchProcessor(logExp)),
  )

  otel.SetTracerProvider(tp)
  otel.SetMeterProvider(mp)
  logglobal.SetLoggerProvider(lp)

  return func(ctx context.Context) error {
    return errors.Join(tp.Shutdown(ctx), mp.Shutdown(ctx), lp.Shutdown(ctx))
  }, lp, nil
}

func loginHandler(w http.ResponseWriter, r *http.Request) {
  ctx, span := tracer.Start(r.Context(), "login.attempt")
  defer span.End()

  user := r.URL.Query().Get("user")
  otp := r.Header.Get("X-OTP")
  authHeader := r.Header.Get("Authorization")

  if user != "alice" || otp != "246810" {
    span.SetAttributes(
      attribute.String("security.event", "auth.failure"),
      attribute.String("enduser.id", user),
      attribute.String("client.address", r.RemoteAddr),
      attribute.Int("http.response.status_code", http.StatusUnauthorized),
    )
    span.SetStatus(codes.Error, "invalid_credentials")

    failedLogins.Add(ctx, 1, metric.WithAttributes(
      attribute.String("auth.factor", "password+otp"),
    ))

    logger.WarnContext(ctx, "authentication failed",
      slog.String("security.event", "auth.failure"),
      slog.String("security.severity", "high"),
      slog.String("enduser.id", user),
      slog.String("client.address", r.RemoteAddr),
      slog.String("auth.header", authHeader),
    )

    http.Error(w, "unauthorized", http.StatusUnauthorized)
    return
  }

  logger.InfoContext(ctx, "authentication succeeded",
    slog.String("security.event", "auth.success"),
    slog.String("enduser.id", user),
  )

  w.WriteHeader(http.StatusOK)
  _, _ = w.Write([]byte("ok"))
}

func main() {
  ctx := context.Background()
  shutdown, lp, err := setupOTel(ctx)
  if err != nil { panic(err) }
  defer func() { _ = shutdown(context.Background()) }()

  failedLogins, err = meter.Int64Counter("security.auth.failures")
  if err != nil { panic(err) }

  logger = otelslog.NewLogger("auth-api", otelslog.WithLoggerProvider(lp), otelslog.WithSource(true))

  mux := http.NewServeMux()
  mux.HandleFunc("/login", loginHandler)

  if err := http.ListenAndServe(":8080", otelhttp.NewHandler(mux, "auth-api")); err != nil {
    panic(err)
  }
}

Step 3: Route, Redact, and Count Events

The important design choice is that you are not treating security telemetry as one generic log stream. You are classifying it at emission time and letting the Collector turn that classification into routing and metrics.

• Traces preserve request context and make it easy to pivot from a suspicious login to upstream latency, retries, or dependency errors.
• Logs capture the event itself with rich attributes such as enduser.id, client.address, and security.severity.
• Metrics provide cheap, fast alert signals. The count connector turns repeated auth failures into a counter without changing app logic again.
• Redaction happens centrally, which is critical when multiple teams and services emit telemetry inconsistently.

If you need realistic test payloads without exposing customer data, sanitize them first with TechBytes’ Data Masking Tool. That is especially useful when replaying login traffic through staging collectors to validate masking rules.

Step 4: Verify the Output

With the Collector running and the Go service started, send a failed login request. You want to confirm four things: the app returns 401, the trace is emitted, the log is routed to the security pipeline, and the auth header gets masked before export.

go run .

curl -i \
  -H 'Authorization: Bearer demo-secret-token' \
  -H 'X-OTP: wrong' \
  'http://localhost:8080/login?user=bob'

Expected result

• The HTTP response should be 401 Unauthorized.
• The Collector should print a trace batch for the failed request.
• The detailed security log output should include security.event=auth.failure.
• The sensitive header should be masked or summarized by the redaction processor, not passed through intact.
• The metrics pipeline should emit security_auth_failures_total with a value of 1.

Logs: security.event=auth.failure
Logs: auth.header=****
Metrics: security_auth_failures_total = 1

You can also verify Collector liveness through the health extension:

curl http://localhost:13133/

If that endpoint is healthy but you still see no telemetry, the problem is usually endpoint mismatch, missing log provider initialization, or a routing condition that never matches.

Troubleshooting and What's Next

Troubleshooting top 3

1. No logs arrive, but traces do. In Go, traces and logs use separate SDK setup. If you forget to create a LoggerProvider and register it globally, the log path becomes a no-op even while traces look healthy.
2. The routing connector never sends records to the security pipeline. Check the exact attribute key and value on the emitted log record. If your app emits security.event=auth_failure but the Collector condition expects auth.failure, nothing matches.
3. Secrets still appear in exported data. The redaction processor only works on fields that reach the Collector. If a secret is embedded inside an unstructured message body, convert that message to structured attributes first, then block the risky keys or values.

What's next

• Replace the debug exporters with your SIEM, data lake, or managed observability backend once the local behavior is correct.
• Add more security events, such as password resets, MFA challenges, privilege changes, and API key failures, using the same security.event pattern.
• Layer alerting on top of security_auth_failures_total, or export it to a metrics backend for rate-based detections.
• Review the official docs for deeper production hardening: OpenTelemetry Go instrumentation, Collector configuration, transforming telemetry, and Collector installation.

The key architectural move is simple: security-relevant behavior must be emitted as telemetry at the moment it happens. Once you do that, OpenTelemetry stops being just observability plumbing and becomes a practical detection substrate.
