WebGPU OIT Reference [2026 Cheat Sheet & Patterns]

Order-independent transparency is still one of the first places a serious WebGPU renderer stops being simple. The good news is that the implementation surface is now stable enough to treat OIT as an engineering choice instead of a research project. This reference is optimized for shipping: what to pick first, which WebGPU calls matter, how to configure the common weighted blended path, and where advanced exact methods start to hurt.

• Weighted blended OIT is usually the best WebGPU default for dense transparent scenes.
• WebGPU still requires HTTPS and is marked Limited availability on MDN.
• Use rgba16float accumulation plus a separate revealage target for the cleanest starter layout.
• Gate timestamp-query and other optional paths behind runtime feature checks.
• Wrap risky setup in pushErrorScope() and tune weights per scene, not per renderer.

Support and Scope

What WebGPU gives you right now

• WebGPU is available only in secure contexts and can run in Web Workers, which is useful when your renderer should stay off the main thread.
• MDN still marks WebGPU as Limited availability, so production rollouts should keep a fallback path or explicit capability gate.
• The core rendering pieces you need for OIT are stable: GPUDevice, GPUTexture, GPUCanvasContext.configure(), render passes, blend states, and WGSL fragment outputs.
• timestamp-query is optional and must be requested only when the adapter exposes it.

What this reference covers

• Weighted blended OIT as the practical default.
• Depth peeling, per-pixel linked lists, and stochastic transparency as escalation paths.
• JS and WGSL snippets you can drop into a renderer after formatting them with the Code Formatter.

Technique Map

Which OIT family fits which scene

Ship weighted blended first when

• Your transparent objects are numerous but visually forgiving.
• You need predictable memory per frame.
• You are building dashboards, CAD previews, medical overlays, particles, or annotation-heavy 3D views.
• You want an implementation that fits standard WebGPU blending and fullscreen composition.

Escalate past weighted blended when

• You must preserve thin intersecting layers exactly.
• You have frequent deep overlap of refractive or near-opaque transparent surfaces.
• Your users will zoom far enough in to catch approximation artifacts.
• You can budget extra passes, atomics, and failure handling.

Commands by Purpose

Core WebGPU calls you actually touch

Minimal bootstrap

if (!navigator.gpu) {
  throw new Error("WebGPU is unavailable in this browser/context.");
}

const adapter = await navigator.gpu.requestAdapter();
if (!adapter) {
  throw new Error("No GPU adapter was returned.");
}

const requiredFeatures = [];
if (adapter.features.has("timestamp-query")) {
  requiredFeatures.push("timestamp-query");
}

const device = await adapter.requestDevice({ requiredFeatures });
const canvas = document.querySelector("canvas");
const context = canvas.getContext("webgpu");

context.configure({
  device,
  format: navigator.gpu.getPreferredCanvasFormat(),
  alphaMode: "premultiplied",
});

Configuration

Recommended starter layout for weighted blended OIT

• Use one floating-point accumulation target, typically rgba16float.
• Use one revealage target that preserves transmittance across the pass.
• Clear accumulation to (0, 0, 0, 0).
• Clear revealage to 1 in every channel you plan to sample.
• Composite into the canvas in a final fullscreen pass.

const size = {
  width: canvas.width,
  height: canvas.height,
};

const accumTex = device.createTexture({
  size,
  format: "rgba16float",
  usage: GPUTextureUsage.RENDER_ATTACHMENT | GPUTextureUsage.TEXTURE_BINDING,
});

const revealTex = device.createTexture({
  size,
  format: "rgba8unorm",
  usage: GPUTextureUsage.RENDER_ATTACHMENT | GPUTextureUsage.TEXTURE_BINDING,
});

const transparentPass = {
  colorAttachments: [
    {
      view: accumTex.createView(),
      clearValue: { r: 0, g: 0, b: 0, a: 0 },
      loadOp: "clear",
      storeOp: "store",
    },
    {
      view: revealTex.createView(),
      clearValue: { r: 1, g: 1, b: 1, a: 1 },
      loadOp: "clear",
      storeOp: "store",
    },
  ],
};

Blend state pattern

const accumBlend = {
  color: { srcFactor: "one", dstFactor: "one", operation: "add" },
  alpha: { srcFactor: "one", dstFactor: "one", operation: "add" },
};

const revealBlend = {
  color: {
    srcFactor: "zero",
    dstFactor: "one-minus-src-alpha",
    operation: "add",
  },
  alpha: {
    srcFactor: "zero",
    dstFactor: "one-minus-src-alpha",
    operation: "add",
  },
};

Transparent pass shader shape

struct TransparentOut {
  @location(0) accum: vec4f,
  @location(1) reveal: vec4f,
};

@fragment
fn fs_transparent(color: vec3f, alphaIn: f32) -> TransparentOut {
  let alpha = clamp(alphaIn, 0.0, 1.0);
  let weight = max(1e-2, pow(alpha + 0.01, 4.0));

  var out: TransparentOut;
  out.accum = vec4f(color * alpha * weight, alpha * weight);
  out.reveal = vec4f(0.0, 0.0, 0.0, alpha);
  return out;
}

Composite pass shader shape

@fragment
fn fs_composite(@builtin(position) pos: vec4f) -> @location(0) vec4f {
  let xy = vec2i(pos.xy);
  let accum = textureLoad(accumTex, xy, 0);
  let reveal = textureLoad(revealTex, xy, 0).r;

  let avgColor = accum.rgb / max(accum.a, 1e-4);
  let outAlpha = 1.0 - reveal;

  return vec4f(avgColor, outAlpha);
}

Advanced Usage

When weighted blended is no longer enough

• Depth peeling is the simplest exact-ish fallback conceptually, but it burns passes quickly.
• Per-pixel linked lists are better when overdraw is deep and exact ordering matters more than simplicity.
• Stochastic transparency is attractive for foliage and noisy content, especially when temporal accumulation already exists.

Per-pixel linked list planning notes

• Store head pointers in a storage buffer indexed by pixel.
• Store nodes in a second storage buffer with color, depth, alpha, and next-pointer fields.
• Allocate nodes with WGSL atomics on a global counter.
• Plan for overflow explicitly; a silent node-pool overflow is a correctness bug, not a perf footnote.
• Resolve in a later pass by sorting or partial ordering per pixel.

Debug and profiling hooks

device.pushErrorScope("validation");

const pipeline = device.createRenderPipeline(descriptor);
const pipelineError = await device.popErrorScope();
if (pipelineError) {
  console.error("Pipeline validation failed:", pipelineError.message);
}

const querySet = adapter.features.has("timestamp-query")
  ? device.createQuerySet({ type: "timestamp", count: 2 })
  : null;

Official references worth keeping open

• MDN: WebGPU API
• MDN: GPU interface
• MDN: GPUDevice.pushErrorScope()
• MDN: GPUDevice.popErrorScope()
• MDN: GPUQuerySet
• W3C: WebGPU Candidate Recommendation Draft

Live Filter and Shortcuts

Drop-in JS filter for a long OIT reference table

<input id="ref-filter" type="search" placeholder="Filter by API, pass, or keyword" />
<table id="ref-table">
  <tbody>
    <tr><td>requestAdapter</td><td>startup</td></tr>
    <tr><td>createTexture</td><td>attachments</td></tr>
    <tr><td>beginRenderPass</td><td>transparent pass</td></tr>
  </tbody>
</table>

<script type="module">
  const input = document.querySelector("#ref-filter");
  const rows = [...document.querySelectorAll("#ref-table tbody tr")];

  function applyFilter() {
    const q = input.value.trim().toLowerCase();
    for (const row of rows) {
      row.hidden = !row.textContent.toLowerCase().includes(q);
    }
  }

  input.addEventListener("input", applyFilter);

  window.addEventListener("keydown", (event) => {
    if (event.key === "/" && document.activeElement !== input) {
      event.preventDefault();
      input.focus();
      input.select();
    }

    if (event.key === "Escape" && document.activeElement === input) {
      input.value = "";
      applyFilter();
      input.blur();
    }
  });
</script>

Suggested shortcuts for your OIT sandbox
